| M (17") | L (18,5") | XL (20") |
M (17")
L (18,5")
XL (20")
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 67.50 | 67.50 | 67.50 | |
| B | Seat tube angle | 74.00 | 74.00 | 74.00 | |
| C | Horizontal top tube | 650.00 mm | 660.00 mm | 670.00 mm | |
| E | Chainstay length | 480.00 mm | 480.00 mm | 480.00 mm | |
| F | Front center | 767.00 mm | 777.00 mm | 796.00 mm | |
| G | Head tube length | 150.00 mm | 150.00 mm | 150.00 mm | |
| H | BB drop | -60.00 | -60.00 | -60.00 | |
| I | Fork length | 535.00 mm | 535.00 mm | 535.00 mm | |
| J | Fork offset | 51.00 mm | 51.00 mm | 51.00 mm | |
| K | Wheelbase | 1241.00 mm | 1251.00 mm | 1270.00 mm | |
| R | Reach | 460.00 mm | 470.00 mm | 485.00 mm | |
| S | Stack height | 673.00 mm | 673.00 mm | 673.00 mm |
