| S | M | L | XL |
S
M
L
XL
|
||
|---|---|---|---|---|---|---|
| A | Head tube angle | 66.50 | 66.50 | 66.50 | 66.50 | |
| B | Seat tube angle | 69.50 | 69.50 | 69.50 | 69.50 | |
| C | Horizontal top tube | 565.00 mm | 600.00 mm | 620.00 mm | 647.00 mm | |
| E | Chainstay length | 450.00 mm | 450.00 mm | 450.00 mm | 450.00 mm | |
| F | Front center | 723.00 mm | 757.00 mm | 779.00 mm | 806.00 mm | |
| G | Head tube length | 100.00 mm | 110.00 mm | 115.00 mm | 120.00 mm | |
| H | BB drop | -38.00 | -38.00 | -38.00 | -38.00 | |
| I | Fork length | 540.00 mm | 540.00 mm | 540.00 mm | 540.00 mm | |
| J | Fork offset | 51.00 mm | 51.00 mm | 51.00 mm | 51.00 mm | |
| K | Wheelbase | 1170.00 mm | 1204.00 mm | 1226.00 mm | 1253.00 mm | |
| R | Reach | 420.00 mm | 450.00 mm | 470.00 mm | 495.00 mm | |
| S | Stack height | 605.00 mm | 614.00 mm | 618.50 mm | 623.00 mm |
