| M (17") | L (19") | XL (21") |
M (17")
L (19")
XL (21")
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 68.00 | 68.00 | 68.00 | |
| B | Seat tube angle | 76.00 | 75.00 | 74.00 | |
| C | Horizontal top tube | 610.00 mm | 622.00 mm | 635.00 mm | |
| E | Chainstay length | 475.00 mm | 475.00 mm | 475.00 mm | |
| F | Front center | 732.00 mm | 732.00 mm | 732.00 mm | |
| G | Head tube length | 160.00 mm | 160.00 mm | 160.00 mm | |
| H | BB drop | -60.00 | -60.00 | -60.00 | |
| I | Fork length | 505.00 mm | 505.00 mm | 505.00 mm | |
| J | Fork offset | 38.00 mm | 38.00 mm | 38.00 mm | |
| K | Wheelbase | 1200.00 mm | 1200.00 mm | 1200.00 mm | |
| R | Reach | 445.00 mm | 445.00 mm | 445.00 mm | |
| S | Stack height | 662.00 mm | 662.00 mm | 662.00 mm |
