| S ( 14") | M (15") |
S ( 14")
M (15")
|
||
|---|---|---|---|---|
| A | Head tube angle | 67.00 | 67.00 | |
| B | Seat tube angle | 74.00 | 74.00 | |
| C | Horizontal top tube | 578.00 mm | 591.00 mm | |
| E | Chainstay length | 460.00 mm | 460.00 mm | |
| F | Front center | 697.00 mm | 710.00 mm | |
| G | Head tube length | 110.00 mm | 120.00 mm | |
| H | BB drop | -50.00 | -50.00 | |
| I | Fork length | 520.00 mm | 520.00 mm | |
| J | Fork offset | 46.00 mm | 46.00 mm | |
| K | Wheelbase | 1153.00 mm | 1167.00 mm | |
| R | Reach | 400.00 mm | 410.00 mm | |
| S | Stack height | 628.00 mm | 637.00 mm |
