| M (18") | L (20") | XL (22") |
M (18")
L (20")
XL (22")
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 69.50 | 69.50 | 69.50 | |
| B | Seat tube angle | 73.00 | 73.00 | 73.00 | |
| C | Horizontal top tube | 605.00 mm | 620.00 mm | 635.00 mm | |
| D | Seat tube length | 460.00 mm | 510.00 mm | 560.00 mm | |
| E | Chainstay length | 455.00 mm | 455.00 mm | 455.00 mm | |
| F | Front center | 668.00 mm | 684.00 mm | 699.00 mm | |
| G | Head tube length | 110.00 mm | 120.00 mm | 130.00 mm | |
| H | BB drop | -60.00 | -60.00 | -60.00 | |
| I | Fork length | 505.00 mm | 505.00 mm | 505.00 mm | |
| J | Fork offset | 38.00 mm | 38.00 mm | 38.00 mm | |
| K | Wheelbase | 1117.00 mm | 1132.00 mm | 1148.00 mm |
