| M (17") | L (18,5") | XL (20") |
M (17")
L (18,5")
XL (20")
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 67.50 | 67.50 | 67.50 | |
| B | Seat tube angle | 73.50 | 470.00 | 73.50 | |
| C | Horizontal top tube | 620.00 mm | 630.00 mm | 653.00 mm | |
| E | Chainstay length | 475.00 mm | 475.00 mm | 475.00 mm | |
| F | Front center | 724.00 mm | 734.00 mm | 753.00 mm | |
| G | Head tube length | 130.00 mm | 130.00 mm | 140.00 mm | |
| H | BB drop | -60.00 | -60.00 | -60.00 | |
| I | Fork length | 520.00 mm | 520.00 mm | 520.00 mm | |
| J | Fork offset | 47.00 mm | 47.00 mm | 47.00 mm | |
| K | Wheelbase | 1193.00 mm | 1203.00 mm | 1223.00 mm | |
| R | Reach | 430.00 mm | 440.00 mm | 460.00 mm | |
| S | Stack height | 642.00 mm | 642.00 mm | 654.00 mm |
