Women's urban e-bike designed for everyday use in the city, whether it's a ride to work or a ride to meet friends at the café. The bike is also ready for crossing light terrain. The WTB Horizon's sturdy 47-width WTB Horizon tires can handle broken city pavement, curbs and other city hazards. With a comfortable saddle and height-adjustable stem, the Metric is destined to become your indispensable urban companion. Features include full lighting controlled directly from the handlebars, integrated mudguards, a minimalist rear rack and a compact kickstand. The Metric GX 1.0 is equipped with the reliable Panasonic GX Power Plus electric drive with 250W of power and 75Nm of torque. The motor is quiet, efficient and economical, with easy control of the support stages from the handlebars. The battery has a capacity of 630Wh and doesn't lose it significantly even after 1,000 charge cycles. Thanks to the fast charging system, the battery can be charged to 80% capacity in just 3-4 hours. It will reach full charge in 6 hours. Just hop in and experience the great feeling of riding!
| 17" (440) | 19" (480) |
17" (440)
19" (480)
|
||
|---|---|---|---|---|
| A | Head tube angle | 71.00 | 71.00 | |
| B | Seat tube angle | 73.50 | 73.50 | |
| C | Horizontal top tube | 590.00 mm | 610.00 mm | |
| D | Seat tube length | 440.00 mm | 480.00 mm | |
| E | Chainstay length | 465.00 mm | 465.00 mm | |
| F | Front center | 652.00 mm | 672.00 mm | |
| G | Head tube length | 170.00 mm | 170.00 mm | |
| H | BB drop | -60.00 | -60.00 | |
| I | Fork length | 477.00 mm | 477.00 mm | |
| J | Fork offset | 46.00 mm | 46.00 mm | |
| K | Wheelbase | 1110.00 mm | 1130.00 mm | |
| R | Reach | 396.00 mm | 416.00 mm | |
| S | Stack height | 657.00 mm | 657.00 mm |
