Discover the undiscovered! Are you going to cover a lot of miles on different surfaces, or pack your bags and cross a continent? Do you want to experience true adventure cycling? The KOYUK 3.0 Gravel Bike is the perfect companion for you. If during your trip you feel like enjoying a bit of dust and terrain, simply take a detour onto unpaved terrain and the KOYUK 3.0 will handle it without a hitch. The KOYUK 3.0 offers the best equipment in the range. It will get you, both with its great design and its unique riding characteristics. The geometry is designed with comfort and the ideal riding position in mind. The equipment is composed of quality and proven components. A complete Shimano GRX groupset is used, which is specifically designed for gravel bikes. A minimalist but very efficient 1x12 drivetrain, combined with a 40-tooth chainsaw, GRX cranks and a cassette with a nice range of 10-51T. Precise trail holding on any surface is essential for gravels, so we built the KOYUK 3.0 with NOVATEC braided wheels shod with WTB Riddler TCS tyres in 37C widths, ready for tubeless use. As the icing on the cake we can mention the comfortable and ergonomic FIZIK Terra Argo X5 saddle. So what are you waiting for? Epic experiences will get you!
| 520 | 540 | 560 | 580 | 600 |
520
540
560
580
600
|
||
|---|---|---|---|---|---|---|---|
| A | Head tube angle | 70.00 | 71.00 | 71.00 | 71.00 | 71.00 | |
| B | Seat tube angle | 73.00 | 73.00 | 73.00 | 73.00 | 73.00 | |
| C | Horizontal top tube | 525.00 mm | 545.00 mm | 558.00 mm | 580.00 mm | 600.00 mm | |
| D | Seat tube length | 440.00 mm | 480.00 mm | 500.00 mm | 540.00 mm | 560.00 mm | |
| E | Chainstay length | 430.00 mm | 430.00 mm | 430.00 mm | 430.00 mm | 430.00 mm | |
| F | Front center | 600.00 mm | 610.00 mm | 623.00 mm | 646.00 mm | 667.00 mm | |
| G | Head tube length | 140.00 mm | 140.00 mm | 150.00 mm | 175.00 mm | 185.00 mm | |
| H | BB drop | -69.00 | -69.00 | -69.00 | -69.00 | -69.00 | |
| I | Fork length | 395.00 mm | 395.00 mm | 395.00 mm | 395.00 mm | 395.00 mm | |
| J | Fork offset | 55.00 mm | 55.00 mm | 55.00 mm | 55.00 mm | 55.00 mm | |
| K | Wheelbase | 1020.00 mm | 1030.00 mm | 1044.00 mm | 1067.00 mm | 1088.00 mm | |
| R | Reach | 361.00 mm | 380.00 mm | 390.00 mm | 405.00 mm | 422.00 mm | |
| S | Stack height | 553.00 mm | 557.00 mm | 566.00 mm | 590.00 mm | 600.00 mm |
