| S (14") | M (16") | L (18") |
S (14")
M (16")
L (18")
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 69.00 | 69.00 | 69.00 | |
| B | Seat tube angle | 73.00 | 73.00 | 73.00 | |
| C | Horizontal top tube | 550.00 mm | 565.00 mm | 580.00 mm | |
| D | Seat tube length | 356.00 mm | 406.00 mm | 457.00 mm | |
| E | Chainstay length | 430.00 mm | 430.00 mm | 430.00 mm | |
| F | Front center | 620.00 mm | 644.00 mm | 659.00 mm | |
| G | Head tube length | 110.00 mm | 110.00 mm | 110.00 mm | |
| H | BB drop | -44.00 | -44.00 | -44.00 | |
| I | Fork length | 480.00 mm | 480.00 mm | 480.00 mm | |
| J | Fork offset | 46.00 mm | 46.00 mm | 46.00 mm | |
| K | Wheelbase | 1055.00 mm | 1070.00 mm | 1085.00 mm |
