Steep climbs, sprints on the flats, or fast downhill descents - all in the comfort of a great road bike that adds to the comfort and enjoyment of long hours in the saddle. The RACE model is a category up from the COMP. It relies on proven classics in the form of the Shimano 105 series, from which you can find brakes, shifters, front derailleur, derailleur and cranks. The wheels spin on Shimano Tiagra hubs and are shod on Mitas Syrinx tyres. The Blade will meet all your expectations, whether you like leisurely rides with friends or want to chase the wind for a race. Dominate all the roads with the model Blade.
| 520 | 540 | 560 | 580 | 600 |
520
540
560
580
600
|
||
|---|---|---|---|---|---|---|---|
| A | Head tube angle | 70.00 | 71.00 | 71.00 | 71.00 | 71.00 | |
| B | Seat tube angle | 73.00 | 73.00 | 73.00 | 73.00 | 73.00 | |
| C | Horizontal top tube | 525.00 mm | 545.00 mm | 560.00 mm | 580.00 mm | 595.00 mm | |
| D | Seat tube length | 450.00 mm | 500.00 mm | 520.00 mm | 540.00 mm | 560.00 mm | |
| E | Chainstay length | 405.00 mm | 405.00 mm | 405.00 mm | 405.00 mm | 405.00 mm | |
| F | Front center | 560.00 mm | 580.00 mm | 595.00 mm | 605.00 mm | 614.00 mm | |
| G | Head tube length | 140.00 mm | 140.00 mm | 155.00 mm | 175.00 mm | 195.00 mm | |
| H | BB drop | -69.00 | -69.00 | -69.00 | -69.00 | -69.00 | |
| I | Fork length | 375.00 mm | 375.00 mm | 375.00 mm | 375.00 mm | 375.00 mm | |
| J | Fork offset | 45.00 mm | 45.00 mm | 45.00 mm | 45.00 mm | 45.00 mm | |
| K | Wheelbase | 955.00 mm | 975.00 mm | 990.00 mm | 1001.00 mm | 1013.00 mm | |
| R | Reach | 363.00 mm | 383.00 mm | 393.00 mm | 402.00 mm | 406.00 mm | |
| S | Stack height | 548.00 mm | 548.00 mm | 563.00 mm | 582.00 mm | 601.00 mm |
