M (18") | L (20") | XL (22") |
M (18")
L (20")
XL (22")
|
||
---|---|---|---|---|---|
A | Head tube angle | 69.50 | 69.50 | 69.50 | |
B | Seat tube angle | 73.00 | 73.00 | 73.00 | |
C | Horizontal top tube | 605.00 mm | 620.00 mm | 635.00 mm | |
D | Seat tube length | 460.00 mm | 510.00 mm | 560.00 mm | |
E | Chainstay length | 455.00 mm | 455.00 mm | 455.00 mm | |
F | Front center | 668.00 mm | 684.00 mm | 699.00 mm | |
G | Head tube length | 110.00 mm | 120.00 mm | 130.00 mm | |
H | BB drop | -60.00 | -60.00 | -60.00 | |
I | Fork length | 505.00 mm | 505.00 mm | 505.00 mm | |
J | Front center | 38.00 mm | 38.00 mm | 38.00 mm | |
K | Wheelbase | 1116.50 mm | 1132.00 mm | 1148.00 mm |
