| M | L | XL |
M
L
XL
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 68.50 | 68.50 | 68.50 | |
| B | Seat tube angle | 73.50 | 73.50 | 73.50 | |
| C | Horizontal top tube | 610.00 mm | 630.00 mm | 655.00 mm | |
| E | Chainstay length | 445.00 mm | 445.00 mm | 445.00 mm | |
| F | Front center | 698.50 mm | 719.50 mm | 745.00 mm | |
| G | Head tube length | 110.00 mm | 120.00 mm | 130.00 mm | |
| H | BB drop | -62.00 | -62.00 | -62.00 | |
| I | Fork length | 510.00 mm | 510.00 mm | 510.00 mm | |
| J | Front center | 46.00 mm | 46.00 mm | 46.00 mm | |
| K | Wheelbase | 1136.50 mm | 1157.50 mm | 1183.00 mm | |
| R | Reach | 426.00 mm | 443.00 mm | 465.00 mm | |
| S | Stack height | 622.00 mm | 631.00 mm | 640.50 mm |
