M (16") | L (18") | XL (20") |
M (16")
L (18")
XL (20")
|
||
---|---|---|---|---|---|
A | Head tube angle | 68.50 | 68.50 | 68.50 | |
B | Seat tube angle | 73.00 | 73.00 | 73.00 | |
C | Horizontal top tube | 585.00 mm | 610.00 mm | 620.00 mm | |
D | Seat tube length | 440.00 mm | 480.00 mm | 520.00 mm | |
E | Chainstay length | 435.00 mm | 435.00 mm | 435.00 mm | |
F | Front center | 670.00 mm | 696.00 mm | 707.00 mm | |
G | Head tube length | 110.00 mm | 120.00 mm | 130.00 mm | |
H | BB drop | -44.00 | -44.00 | -44.00 | |
I | Fork length | 480.00 mm | 480.00 mm | 480.00 mm | |
J | Front center | 47.00 mm | 47.00 mm | 47.00 mm | |
K | Wheelbase | 1101.00 mm | 1127.00 mm | 1138.00 mm | |
R | Reach | 409.00 mm | 431.00 mm | 438.00 mm | |
S | Stack height | 576.00 mm | 585.00 mm | 594.00 mm |
